Injection of Botulinum Toxin to the Glabellar Region



Injection of Botulinum Toxin to the Glabellar Region


Jonathan Sykes

Peter Palhazi

Amir Allak





ANATOMY



  • The corrugator supercilii (CS) are paired, obliquely oriented muscles located in the inferomedial brow deep to the inferior portion of the frontalis muscles.


  • The CS muscle originates from the bony superomedial orbital rim and passes in a superior and lateral direction to insert onto the fascia of the frontalis muscle and into the overlying skin (FIG 1).


  • In addition to coursing superiorly and laterally from its insertion, the CS becomes more superficial as it travels laterally.






    FIG 1 • Cadaveric dissection of the relationship of the corrugator muscle to the nasal root and frontalis. CS, corrugator supercilii.


  • The CS muscle body is pierced by the supraorbital and supratrochlear neurovascular bundles carrying sensory input to the trigeminal nerve (V1). The nerves then pierce the frontalis muscles approximately 2 to 3 cm above the supraorbital rim to travel subcutaneously to the forehead and scalp (FIG 2).


  • The medial head of the CS has motor innervation from the zygomatic branch of the facial nerve, whereas the lateral portion is supplied by the temporal branch of the nerve.


  • Contraction of the muscle causes vertical grooves in the glabellar skin and imparts an angry expression. Contraction also causes an inferomedial descent of the medial clubhead of the brow.


  • The procerus is a midline flat and pyramidally shaped muscle located at the root of the nose contributing to upper nasal contour.


  • The procerus originates from the periosteum and perichondrium of the nasal bones and upper lateral cartilages and from the fascia of the nasal superficial musculoaponeurotic system (SMAS) (see FIG 2).


  • Procerus inserts into the midline skin overlying the nasal root and interdigitates superiorly with the frontalis muscle (see FIG 2).


  • The motor innervation to the procerus is supplied by the zygomatic branch of the facial nerve.


  • Contraction of the midline muscle is responsible for horizontal glabellar rhytids, transverse rhytids on the nasal dorsum, and descent of the medial brow.






FIG 2 • Cadaveric dissection with coronal forehead flap elevated viewed from the superior aspect of the head. L, patient’s left; R, patient’s right; SO, supraorbital neurovascular bundle; ST, supratrochlear neurovascular bundle; NR, nasal root (indicating midline); PM, procerus muscle.
