Immunosuppressant eras
Time period
Agent(s) used
Organs transplanted
Experimental era
1954–1962
Prednisone alone
Kidneys of identical twins
Azathioprine era
1962–1983
Prednisone & azathioprine
Cadaveric kidneys
Cyclosporine era
1983–1990
Cyclosporine
Extra-renal transplants
Modern era
1990–present
Tacrolimus & sirolimus
Extra-renal transplants with increased organ survival
Immunosuppressive agents can be divided into induction agents and maintenance agents. Induction agents are antibodies given peri-operatively to induce tolerance to the graft by depleting host T-cell activity. Newer agents, basiliximab and daclizumab, rabbit antithymocyte globulin and anti-interleukin-2 receptor antibodies, respectively, are used in the majority of inductions [53]. Maintenance immunosuppressives can be classified as antimetabolites, calcineurin inhibitors, and rapamycin each of which have different mechanisms of action allowing for synergistic effects when used in combination.
Azathioprine acts as an antimetabolite. AZA, a purine analog, blocks B and T-cell proliferation through the inhibition of purine synthesis and metabolism. Adverse effects of AZA such as bone marrow suppression and hepatitis result from its broad inhibition of purine synthesis [53]. AZA was recently reported to increase photosensitivity to ultraviolet A light (UVA), and also enables UVA to directly damage DNA [54]. Another antimetabolite, mycophenolate mofetil (MMF), is a prodrug that is metabolized into the active compound mycophenolic acid which inhibits de novo purine biosynthesis. MMF, approved in 1995 for use in renal transplant recipients, is now being used widely in place of AZA [55]. A switch to MMF can normalize photosensitivity to UVA and may contribute to reducing additional DNA damage and thus SCC [54]. In addition to bone marrow suppression, MMF also causes gastrointestinal distress. Improved gastrointestinal tolerability has been shown with the use of an enteric coated formulation in stable renal transplant recipients [56].
Cyclosporine (CsA), a calcineurin inhibitor, blocks activation of T-cells by preventing the expression of cytokine interleukin-2 (IL-2). CsA binds to cytoplasmic nuclear factor of activated T cells (NFAT), a family of transcription factors, preventing transcription of growth factors such as IL-2 [53]. CsA is also known to enhance the expression of transforming growth factor-β (TGF- β). TGFβ- is known to inhibit IL-2-stimulated T-cell proliferation and generation of cytotoxic T lymphocytes [55]. The carcinogenic effect of CsA has been shown in a study where patients treated with corticosteroids, azathioprine, and CsA had a three-fold increase in risk of skin cancer when compared to patients on corticosteroids and azathioprine alone [11]. Other studies have found lesions occur earlier in CsA-treated patients [11, 50]. CsA may have a direct cellular effect which promotes the progression of cancer independently from its effects on host immune cells. An ex vivo study showed that CsA-treated adenocarcinoma cells transformed non-invasive cells to invasive cells with pseudopodia and increased cell motility [24]. These changes were dose-dependent and reversible. Monoclonal antibodies directed against TGF-β prevented these changes indicating CsA-induced TGF- β production as a mechanism.
Tacrolimus (TAC), another calcineurin inhibitor, binds the cytoplasmic protein, FK-binding protein (FKBP), and prevents production of IL-2 by inhibiting phosphatase activity of calcineurin. TAC is 100 times more potent than CsA [57] and, in addition to nephrotoxicity, its side effects include glucose intolerance and reversible alopecia [55]. Tacrolimus has been shown in vitro to promote tumor growth in human hepatoma cells [58]. It has been suggested that tacrolimus may be less oncogenic than CsA based on a lower prevalence of enhanced TGF-β transcription [59].
Sirolimus, also known as rapamycin, is a relatively new antitumor agent, which shows promise in decreasing the risk of NMSC in OTRs. The cellular target of sirolimus, mTOR or mammalian target of rapamycin, is considered a member of P13K family kinases [60]. Sirolimus binds the intracellular protein FK-binding protein-12 (FKBP12) forming a high affinity complex which in turn binds mTOR. The binding of mTOR, also called FRAP (FKBP-rapamycin associated protein), ultimately results in cell cycle arrest at G1/S phase through the dephosphorylation and inactivation of p70 ribosomal protein S6 kinase. Consequently, this leads to the inhibition of IL-stimulated lymphocyte division and antibody production [55]. More specifically, sirolimus inhibits the response to interleukin-2 (IL-2) thereby blocking activation of T- and B-cells [56].
Sirolimus has been shown to have antineoplastic properties in both in vitro and in vivo studies [61–63]. Studies have shown a decrease in metastatic area in mice treated with rapamycin and an increase in tumoral area in mice treated with CsA. The decrease in tumor growth in mice treated with rapamycin is attributed to a decrease in neovascularization whereas the increase in tumor growth in CsA-treated mice was associated with extensive neovascularization. Sirolimus has been shown to inhibit vascular endothelial growth factor (VEGF) both in vitro and in vivo [63]. Another study using a human renal cell cancer pulmonary metastasis model showed sirolimus reduced, whereas CsA increased, the number of pulmonary metastases. Circulating levels of VEGF and TGF-B were found to be lower in rapamycin-treated mice than in control or CsA-treated mice [64].
Despite the relatively recent introduction of sirolimus, its use as an immunosuppressive agent in OTR has been studied. The incidence of skin cancer in sirolimus-treated organ transplant recipients was assessed at 2 years post-transplantation and comprised 1981 patients from five multi-center studies. All patients received CsA and corticosteroids and had varying combinations of sirolimus (SRL), AZA or placebo [65]. The study showed that patients receiving SRL immunotherapy without CsA have a lower incidence of malignancy than patients receiving both SRL and CsA. However the patients on combination therapy showed significantly lower incidence of skin cancer compared to CsA and placebo. The study also found that use of SRL concentration-controlled immunotherapy and early elimination of CsA resulted in significantly lower rates of malignancy.
Sirolimus is well tolerated and has the advantage of less nephrotoxicity and elevating blood pressure compared to calcineurin inhibitors. Side effects of sirolimus include hyperlipidemia, thrombocytopenia, leucopenia, and anemia [66]. Although sirolimus, as well as preliminary data of its derivative CCI-779 (everolimus) look promising, it is important to recognize that further studies will need to take place to further assess its effects due to the relatively new development of the drug and the latency of onset of NMSC in OTRs.
HLA Subtypes and NMSC
Recipient HLA type has been suggested as a possible risk factor for NMSC in OTRs. Several theories on how HLA type may play a role in increasing the risk of NMSC exist. Studies investigating HLA types and the risk of NMSC in OTR have been done with conflicting results [67]. Two of the largest studies have found HLA-A11 to increase post-transplant risk of NMSC [67, 68]. Of these two studies, one was able to successfully identify a subset of Caucasian renal transplant recipients in a northern climate who were at increased risk at both short and long-term follow up after transplantation. This increased risk associated with HLA-A11 is only conferred in patients with lighter, sun-sensitive skin [67]. This study suggests a role for more aggressive monitoring in patients with HLA-A11 type. There are recurring findings in different studies showing HLA- DR1, HLA- DR4 and HLA- B27 and their association with non-melanoma skin cancer, but no definitive conclusions have been reached [69]. Further studies need to be conducted to confirm these findings and perhaps identify other HLA types which may have significance to OTRs and their risk of NMSC.
Treatment and Follow-Up Recommendations of NMSC in OTR
Management of OTR as a dermatologist is challenging due to the chronic immunosuppression and progressively increasing risk of NMSC. The American Society of Transplantation (AST) recommends that patients perform monthly skin self-examinations and have their skin examined by a physician annually [70]. A survey that weighed the advantages and disadvantages of various clinical settings of OTR concluded that regardless of the clinical design, certain principles are key to providing the best care [71]. The survey stressed the importance of: close communication with the transplant team, education of other care providers regarding OTRs’ unique dermatologic concerns, patient education as a key to prevention, and close follow-up determined by the risk of skin cancer.
The International Transplant-Skin Cancer Collaborative (ITSCC) has combined data from many studies to develop useful clinical guidelines for the treatment of skin cancer in OTR [72]. Patients should be followed according to their individual risk factors. For low-risk individuals with no history of skin cancer, a yearly follow-up is recommended. For higher-risk individuals with a history of sunburns, fair skin type, or of older age, a 6–12 monthly schedule is advised. If there is any history of NMSCs, AKs or warts, then follow-up should be scheduled at 3–6-month intervals. For both high-risk SCCs and multiple NMSCs, a follow-up should be scheduled for every 3 months. Follow-up can be as frequent as once a month for patients with metastatic SCC [73, 74]. Precancerous lesions such as warts and actinic keratoses should be recognized and treated early to reduce the viral burden and the extent of intraepithelial neoplasia (See Figs. 39.1, 39.2, and 39.3). Treatment of precancerous lesions includes: cryosurgery, topical 5-fluorouracil, topical imiquimod, and electrodesiccation and curettage (ED&C). Photodynamic therapy may be used in OTRs for the treatment of actinic keratoses not responsive to conventional treatments, and superficial NMSC [20]. Topical and systemic retinoids may be used as chemoprevention of skin cancer but are only effective while the retinoid is being used [75, 76]. NSAIDs such as topical diclofenac are being used to treat AKs in those patients that prefer not to use 5-FU [73].
Fig. 39.1
Fifty-eight year old heart transplant patient who was previously treated with radiation to the circumoral area for multiple cutaneous squamous cell carcinomas. This is a recurrent moderately differentiated squamous cell carcinoma within the radiation field
Fig. 39.2
Fifty-eight year old heart transplant patient with multiple actinic keratoses of the dorsal hands
Fig. 39.3
Fifty-eight year old heart transplant patient with multiple actinic keratoses of the forehead and a lesion on the left nasal sidewall which was biopsied to reveal well-differentiated squamous cell carcinoma
Some emerging treatments include epidermal growth factor (EGFR) inhibitors, ingenol mebutate (IM) and afamelanotide. There is increasing evidence showing amplification and overexpression of EGFR in SCCs. Cetuximab, a monoclonal antibody to the EGFR receptor, has been used primarily in metastatic SCC of the head and neck. Ingenol mebutate (IM) is a new topical medication that has been recently approved by the FDA for treating AKs of the scalp, trunk and extremities. It has the added benefit of requiring fewer applications than 5-fluorouracil, diclofenac and imiquimod. The mechanism of action is not known, but two proposed mechanisms are direct damage to the mitochondrial membrane, leading to rapid cellular necrosis and the release of pro-inflammatory mediators. The other mechanism may involve the maturation of B cells that produce antibodies that lead to neutrophil-mediated, antibody-dependent cellular cytotoxicity. Afamelanotide is a synthetic analog of melanocyte stimulating hormone (α-MSH) that may protect skin from UVB damage [20].
Less aggressive SCC can be managed with destructive modalities such as: ED&C, cryosurgery, Mohs micrographic surgery, or excised with postoperative margin assessment (See Table 39.2).
Table 39.2
Cutaneous squamous cell carcinomas in organ transplant recipients
Characteristic | Less aggressive SCC | More aggressive SCC |
---|---|---|
Size: | ||
‘Mask’ areas of facea, genitals, hands, feet | <0.6 cm | >0.6 cm |
Cheeks, forehead, neck, scalp | <1.0 cm | >1.0 cm |
Trunk & extremities | <2.0 cm | >2.0 cm |
Rate of growth | Static or slow-growing | Rapid |
Ulceration | No | Yes |
Clinical margins | Distinct, well-defined | Indistinct |
Satellite lesions | No | Yes |
Neurotropism | Absent | Present |
Histology: | ||
Invasiveness | In situ/invasion limited to papillary dermis | Deep extension into subcutaneous fat |
Perivascular or intravascular invasion | No | Yes |
Differentiation | Well-differentiated | Poorly-differentiated |
Aggressive SCCs should be removed completely using excisional techniques including Mohs, excision with intraoperative frozen section control, or excision with postoperative margin assessment. Additional modalities may be useful in some instances. Radiation therapy may be considered as adjunctive therapy or as a primary modality for inoperable tumors (Fig. 39.1). Although not routinely used, small studies are beginning to support the role of sentinel lymph node biopsy (SLNB) in the evaluation of high risk NMSC [77].
Chemoprophylaxis with oral retinoids such as acitretin has been shown to be effective in reducing the rate of development of premalignant and malignant lesions in OTR [76, 78]. This effect is only exhibited while the patient is actively taking the retinoid. After cessation of the drug, the rate of development of lesions returns to baseline or may even exceed the prior rate of development. Retinoids have several side effects which are often very difficult for patients to tolerate on a long-term basis. These side effects include: dry skin, dry lips, significant hair loss, pruritus and arthralgias [76].
Areas of multiple SCC, such as the dorsum of the hand, have been successfully treated with excision and split-thickness skin grafting. Although the grafted area remains lesion-free for an extended period, this procedure has significant morbidity and requires an extensive recovery [79, 80].
In cases of life-threatening skin-cancers, reduction of immunosuppression may be considered. Studies have shown that renal transplant recipients with very aggressive SCC have an improved prognosis following dose reduction compared to those whose immunosuppression was left unchanged [81]. It has also been shown that graft function may continue despite reduction of immunosuppression [82, 83]. It is important when considering reduction of immunosuppressive therapy that it is done in consultation with the transplant physician. If the need to reduce the level of immunosuppression is warranted, transplant physicians often prefer to lower the dose of AZA first as CsA confers better allograft survival [84]. Introducing mTOR inhibitors, or substituting them for a calcineurin inhibitor, may further reduce SCC formation [54].
Conclusion
Skin cancer in OTR is a continuing problem as the number of living OTR grows due to an increasing number of transplants performed and longer patient & graft survival time. This, in turn, has lead to a growing number of patients on chronic immunosuppression. Chronic immunosuppression, along with other risk factors, places these patients at higher risk of developing malignancies, the most common being cutaneous malignancies. Further investigation of these risk factors and the identification of others will hopefully lead to improved prevention, management and treatment of these patients. In addition, further investigation of current immunosuppressive regimens and the development of new immunosuppressive agents, will hopefully lead to decreased morbidity and mortality, particularly from cutaneous malignancies.
Management of these patients requires a multi-faceted approach involving the transplant team, dermatologists, other care providers and the patients. It is important as dermatologists to make all those involved in the care of these patients aware of their unique dermatologic concerns. Treatment and follow up may then be determined on an individual basis based on the patient’s risk factors and the relative risk of the skin cancer.
Questions
- 1.
Which of the following risk factors for the development of non-melanoma skin cancer is most important in both the general population and organ transplant recipients?
- A.
Fitzpatrick skin type
- B.
Ultraviolet radiation
- C.
Family history
- D.
Immunosuppression
